ZGM 1240A
本钻机是集机、液、电等技术为一体的综合体，采用“软”连接来构成这个综合体系。具有工作稳定、行走速度快、工作效率高、钻具使用寿命长、能量损耗低、操作简单及具有自动保护等多种功能，它能应用于不同的场合、不同的领域，并具有极强的应变能力，可以满足用户的多种需要。
主要用途及试用范围：适用于建筑施工、公路施工，以及其他的机械化工程。该钻车使用接卸式钻杆、钻凿垂直、倾斜、水平主打直径为90-165毫米孔，钻孔深度可达25米。
ZGM 1240A Separated DTH Surface Drill Rig
The drilling rig is a combination of machine, liquid, electricity and other technologies, using "soft" connection to form this integrated system. It has many functions, such as stable work, fast walking speed, high working efficiency, long service life of drilling tools, low energy loss, simple operation and automatic protection. It can be applied to different occasions, different fields, and has extremely strong strain ability, which can meet the needs of users.
Main uses and trial scope: suitable for construction, highway construction, and other mechanized works. The drill car uses the joint-unloading drill pipe, drilling vertical, inclined, horizontal main diameter of 90-165 mm hole, the maximum drilling depth can reach 25 meters.
