先导式减压阀
类型 3DR
- 规格 16
- 组件系列 5X
- 大工作压力 250 bar
- 大流量 220 l/min
博世力士乐
先导式减压阀
特点
- 用于减少（P 到 A）和限制（A 到 T）系统压力的阀
- 用于底板安装
- 油口安装面符合 ISO 4401-07-07-0-05
- 符合样本 RC 45056 的底板（单独订购）
REXROTH力士乐减压阀3DR16P5-5X-250Y-00M
- 4 个压力等级
- 4 个调节元件，可选：
·旋钮
·六角套筒和保护帽
·带刻度可锁定旋钮
·带刻度旋钮
订货代码
"3DR16P*-5X/*Y/00**"
"3DR"--三通减压阀
"16"--规格16
"P"--底板安装
"*"--调节元件：
4 = 旋钮
5 = 六角套筒和保护帽
6 = 带刻度可锁定旋钮
7 = 带刻度旋钮
REXROTH力士乐减压阀3DR16P5-5X-250Y-00M
"5X"--组件系列 50 至 59（50 至 59：安装和连接尺寸不变）
"*"--zui高压力设置：
50 = 压力设置zui高为 50 bar
100 = 压力设置zui高为 100 bar
200 = 压力设置zui高为 200 bar
250 = 压力设置zui高为 250 bar
"Y"--先导供油：
Y = 内部先导供油，外部先导泄油
"00"--无行程限位器
"*"--密封材料：
M = NBR 密封件
V = FKM 密封件（可应要求提供其它密封件）
注意！请务必遵守密封件与所用液压油的兼容性！
REXROTH力士乐减压阀3DR16P5-5X-250Y-00M
我司经销相关型号如下：
R900932324 3DR10P4-6X/50Y/00M
R900916657 3DR10P4-6X/100Y/00M
R900917795 3DR10P4-6X/100Y/00V
R900917787 3DR10P4-6X/200Y/00M
R900917797 3DR10P4-6X/200Y/00V
R900917791 3DR10P4-6X/315Y/00M
R900917790 3DR10P4-6X/315Y/00V
R900921663 3DR10P5-6X/50Y/00M
R900973873 3DR10P5-6X/50Y/00V
R900916663 3DR10P5-6X/100Y/00M
R900917786 3DR10P5-6X/100Y/00V
R900916660 3DR10P5-6X/200Y/00M
R900917788 3DR10P5-6X/200Y/00V
R900916661 3DR10P5-6X/315Y/00M
R900917794 3DR10P5-6X/315Y/00V
R901015252 3DR10P6-6X/50Y/00M
R900916659 3DR10P6-6X/100Y/00M
R900917793 3DR10P6-6X/100Y/00V
R900917792 3DR10P6-6X/200Y/00M
R900917785 3DR10P6-6X/200Y/00V
R900917784 3DR10P6-6X/315Y/00M
R900917796 3DR10P7-6X/100Y/00M
R901068395 3DR10P7-6X/100Y/00V
R900737366 3DR10P7-6X/200Y/00M
R901030861 3DR10P7-6X/200Y/00V
R901149319 3DR10P7-6X/315Y/00M
3DR 16 三通先导式减压阀
R900976027 3DR16P4-5X/50Y/00M
R900917782 3DR16P4-5X/100Y/00M
R900917780 3DR16P4-5X/100Y/00V
R900916667 3DR16P4-5X/200Y/00M
R900917772 3DR16P4-5X/200Y/00V
R900917781 3DR16P4-5X/250Y/00M
R900919502 3DR16P5-5X/50Y/00M
R900942090 3DR16P5-5X/50Y/00V
R900916666 3DR16P5-5X/100Y/00M
R900917774 3DR16P5-5X/100Y/00V
R900916668 3DR16P5-5X/200Y/00M
R900917773 3DR16P5-5X/200Y/00V
R900917775 3DR16P5-5X/250Y/00M
R900916670 3DR16P5-5X/250Y/00V
R900917777 3DR16P6-5X/100Y/00M
R900917779 3DR16P6-5X/100Y/00V
